10,000 Lbs Capacity 4' X 4' Industrial Floor Scale With DWP-102N Indicator
10,000 Lbs Capacity 4' X 4' Industrial Floor Scale NTEP DWP-102N Indicator
This is a professional floor scale for industrial or shipping use
This is a 10000 Lbs /1 Lb. Floor/Pallet/Shipping Scale
It is the durable scale with fully testing before ship
Please read the following specifications of this high-performance balance
Product Features:
Four high quality alloy load cells ensure accuracy in full capacity range
Standard true 4' X 4' (48" X 48") size
10,000 Lbs Weighing capacity with 150% overload protection
25" deck plate with lifting eyes, well painted
High quality indicator with built-in rechargeable battery
LB/KG selection
Tare function covers units full capacity range
With counting function
The scale could be used on the field with no power source around
15' cable for indicator
Specifications:
Scale Size: 4' (D) x 4' (W) x 4.5" (H)
Weighing Modes: KG and LB
Capacity/Accuracy: 10000 lb/1lb
Platform Size: 4' x 4'
Platform Material: 0.25" deck plate.
Power: 110+/-11V 60 HZ or Built-in Rechargeable Battery
Indicator:
The Digiweigh DWP-102N weighing indicator is an easy to use indicator which can be used with floor scales, bench scales, pallet truck scales, forklift scales and other scales.
It has an internal resolution of 300,000 counts and 50,000 external counts.
It has a large LED display that is bright and gives great visibility that is independent of the ambient lighting conditions.
It can be connected to a computer with help of an RS-232 port. It can also be integrated in a network.
The DIGIWEIGH DWP-102N weighing indicator has a swivel stand and can be placed on the desk or if desired mounted on the wall.
For a very low additional charge you can get a compatible desktop software.
The full scale input signal is 30mV which includes the dead load
The minimum sensitivity is 1.0uV / grad
The input impedance is 30mΩ, typical
It has an internal resolution of 300,000 counts and 50,000 external counts.
The display resolution is 50,000 max
The measurement rate is 10 Meas / sec
The system linearity is within 0.02% of FS
The calibration method is software calibration
Excitation Voltage : +10V DC, 4 x 350Ω load cells
The digital filtering is software selectable
Serial Port : Full Duplex, 1200, 2400, 4800, 9600, 19200 Baud
The display is 0.56” 7-segment LED display showing 6 digits
Additional symbols include Net, Gross, Stable, Tare, lb, kg, Zero, PCS
It has a 14-key flat membrane panel keyboard
Power: 9V DC, 500mA Femal & Rechargeable battery
The operating temperature is : -10 - 40C
Applications:
You can use it as a shipping scale, weight control scale, animal scale etc.
Please note this scale is NOT NTEP approved, so it is NOT certified for trade.
